PE 79.50.517 | FPE
Festpunkte für Festpunktrohrschellen, PE 100, SDR 17, kurz, spangebend hergestellt
- zum Heizelementstumpfschweißen
- nach DIN 3567
- s1/s2 = Schellenabmaße
- Schellen dürfen keine Radialkraft auf den Festpunkt aufweisen
- Schelle bis DN500 nach DIN 3567, ab DN 560 Sonderschelle
- vor Verwendung ist zu prüfen, ob die Kräfte, resultierend aus der Rohrverlegung, vom Festpunkt aufgenommen werden können.
Artikel | de | b | D | l1 | s1 | Z | Gewicht [kg] | VE |
---|---|---|---|---|---|---|---|---|
790550517 | 50 | 45 | 68 | 40 | 57x40 | 180 | 0,180 | 1 |
790650517 | 63 | 45 | 86 | 40 | 77x40 | 180 | 0,300 | 1 |
791150517 | 110 | 55 | 146 | 70 | 133x50 | 260 | 1,000 | 1 |
791450517 | 140 | 55 | 172 | 70 | 159x50 | 260 | 1,400 | 1 |
792250517 | 225 | 65 | 281 | 80 | 267x60 | 330 | 5,350 | 1 |
792550517 | 250 | 65 | 286 | 80 | 273x60 | 330 | 5,800 | 1 |
793150517 | 315 | 65 | 340 | 80 | 324x60 | 330 | 7,240 | 1 |
793550517 | 355 | 65 | 381 | 80 | 368x60 | 330 | 8,300 | 1 |
794550517 | 450 | 75 | 525 | 95 | 508x70 | 390 | 20,400 | 1 |
790750517 | 75 | 45 | 98 | 40 | 89x40 | 180 | 0,400 | 1 |
790950517 | 90 | 55 | 121 | 70 | 108x50 | 260 | 0,300 | 1 |
791250517 | 125 | 55 | 156 | 70 | 140x50 | 260 | 1,100 | 1 |
791650517 | 160 | 55 | 184 | 70 | 169x50 | 260 | 1,500 | 1 |
791850517 | 180 | 55 | 206 | 80 | 191x50 | 330 | 2,600 | 1 |
792050517 | 200 | 55 | 231 | 80 | 216x50 | 330 | 3,400 | 1 |
792850517 | 280 | 65 | 331 | 80 | 318x60 | 330 | 7,000 | 1 |
794050517 | 400 | 75 | 426 | 95 | 407x70 | 390 | 12,100 | 1 |
795050517 | 500 | 75 | 538 | 95 | 521x70 | 390 | 19,800 | 1 |
795650517 | 560 | 95 | 623 | 95 | 603x90 | 420 | 30,400 | 1 |
796350517 | 630 | 95 | 678 | 95 | 658x90 | 420 | 34,500 | 1 |
797150517 | 710 | 95 | 780 | 95 | 760x90 | 420 | 46,900 | 1 |
798050517 | 800 | 95 | 830 | 95 | 810x90 | 420 | 48,600 | 1 |
