221.454.3X | TKDBEV-T/CP-DA
3-Wege-Kugelhahn TKD, PVC-U, d 20 - d 63, PE LS Stutzen, T-Bohrung, DA
- 3-Wege-Kugelhahn aus PVC-U mit pneumatischem Stellantrieb
- Funktion: doppelt wirkend, inklusive optischer Stellungsanzeige
- Kugel mit T-Bohrung
- Standardkugelstellung: 1
- Steuerdruck: Standard 5 bar
- reduzierter Steuerdruck: auf Anfrage
- Steueranschluß: G 1/8'' Namur (DN15) G 1/4'' Namur (DN20 - DN50)
- Anschluss: PE-LS-Stutzen zum Heizelementstumpf- und Heizwendelschweißen (PN16 bei Wasser 20 °C)
- Dichtung: wahlweise PTFE/EPDM oder PTFE/FKM
![3-Wege-Kugelhahn TKD, PVC-U, d 20 - d 63, PE LS Stutzen, T-Bohrung, DA 3-Wege-Kugelhahn TKD, PVC-U, d 20 - d 63, PE LS Stutzen, T-Bohrung, DA](/pim/fip-de/images/image-thumb__56235__product-detail/tkdbev-cp_21-453-454-30-31_sw_b.png)
Dichtung: EPDM
Artikel | d | DN | PN | Antrieb | Dichtung | VE |
---|---|---|---|---|---|---|
221454030301020 | 20 | 15 | 16 | DA | EPDM | 1 |
221454030301025 | 25 | 20 | 16 | DA | EPDM | 1 |
221454030301032 | 32 | 25 | 16 | DA | EPDM | 1 |
221454030301040 | 40 | 32 | 16 | DA | EPDM | 1 |
221454030301050 | 50 | 40 | 16 | DA | EPDM | 1 |
221454030301063 | 63 | 50 | 16 | DA | EPDM | 1 |
Dichtung: FKM
Artikel | d | DN | PN | Antrieb | Dichtung | VE |
---|---|---|---|---|---|---|
221454031301020 | 20 | 15 | 16 | DA | FKM | 1 |
221454031301025 | 25 | 20 | 16 | DA | FKM | 1 |
221454031301032 | 32 | 25 | 16 | DA | FKM | 1 |
221454031301040 | 40 | 32 | 16 | DA | FKM | 1 |
221454031301050 | 50 | 40 | 16 | DA | FKM | 1 |
221454031301063 | 63 | 50 | 16 | DA | FKM | 1 |
